Product Details
ASCEND-14L-BH SPECS
Max Height
68.9" (175 cm)
Max Height (w/o Column)
60.3" (153 cm)
Min Height
5.1" (13 cm)
Load Capacity
30 lb (14 kg)
Folded Length
21.1" (54 cm)
Folded Diameter
3.4" (8.6 cm)
Leg Sections
4
Head Type
Integrated 22 mm Arca-compatible ball head
Weight
3.38 lb (1.53 kg)
IS THE ASCEND-14L-BH RIGHT FOR YOU?
- Best for: Tall users, alpine terrain, and situations where extra standing height and long sightlines matter.
- Choose it if: You need an all-in-one travel tripod with integrated ball head that still reaches 68.9" (175 cm) without sacrificing stability.
- Carry profile: 3.38 lb (1.53 kg), 21.1" (54 cm) folded, 3.4" (8.6 cm) diameter.
- Height range: 68.9" (175 cm) max height, 60.3" (153 cm) max height without column, 5.1" (13 cm) minimum height.
- Capacity: 30 lb (14 kg) rating for telephoto camera rigs, spotting scopes, or rifles with optics.
- Interface: Integrated 22 mm Arca-Swiss compatible ball head with panning and tilt control.
- Legs: Series 1, 4-section carbon fiber legs with short-throw twist locks for quick deployment.
- Use cases: Photography, glassing, and field spotting where compact transport and extended height are equally important.
The RRS® Ascend-14L-BH
Tall, integrated support for serious field work
The Ascend-14L-BH is a Series 1 carbon fiber travel tripod with an integrated 22 mm ball head, built for photographers and backcountry hunters who need extra standing height, dependable stability, and a compact, all-in-one system that is easy to carry into rugged terrain.
ASCEND-14L-BH FEATURES
- Premium carbon fiber legs and low center of gravity design help resist flex, vibration, and wind for sharp, stable shots.
- 30 lb (14 kg) conservative load rating handles telephoto lenses, spotting scopes, or rifles with optics without sagging.
- Short-throw twist locks and four leg sections allow fast deployment and height changes, even in adverse weather.
- Height range from 5.1" (13 cm) to 68.9" (175 cm) with independent leg angles for stability on slopes or rocky terrain.
- Integrated 22 mm Arca-Swiss compatible ball head provides smooth panning, tilting, and quick-release mounting.
- Weather-sealed o-rings and precision-machined components are designed, manufactured, and hand-assembled in the USA.
- Additional details include a repositionable drop notch, integrated hex key, bubble level, and weight hook for wind resistance.
- Folds to 21.1" (54 cm) with a compact 3.4" (8.6 cm) diameter for easy packing on long hikes or travel.
New to Professional Tripods?
Learn more about how to choose the right tripod and what makes Really Right Stuff tripods different. The guide explains tripod types, materials, stability factors, accessories, and setup best practices—helping you build a rock-solid support system for photography, hunting, competition shooting, and field use.
WHAT'S IN THE BOX?
- (1) Ascend-14 Tripod (in selected size)
- (2) 5/32" hex keys (to adjust leg angle tension)
- (1) 3/32" hex key (to adjust the tension on the column lock)
- (1) QR-Code Reference Card for User Manual
