TA-LBC: Round Lever Release Clamp


Secure your gear with RRS Round Lever-Release Clamp. Compatible with Series-3 Leveling Base (TA-3-LB) & Series-2/Universal Leveling Base (TA-2U).

Adding to bag… The item has been added


Round Lever Release Clamp, 60mm jaws
Why should you invest in a quick-release system? Because screwing your camera or lens onto a platform with standard 1/4"-20 screw is tedious and insecure. Not only is it a hassle to screw your gear onto that platform, but once installed the camera or lens is free to rotate; there's nothing to prevent it from coming loose. Why invest your money in a tripod and tripod head only to compromise your shots with an insecure connection between camera and head? Instead, adopt the Really Right Stuff quick-release system.

The Really Right Stuff quick-release system is based on the Arca-Swiss standard and has two parts: a quick-release clamp and a quick-release plate. You always need both pieces of the system. The clamp will stay on your tripod head/accessory all the time, and the plate will stay on your camera all the time. You will need to purchase a separate quick-release plate for each camera or collared, telephoto lens that you want to mount in the quick-release clamp on your tripod head.

Clamp jaws open and close in one of two ways: by twisting a knurled knob on our tried & true screw-knob clamps; or by flipping a single lever on our innovative, patented lever-release clamps. The graceful Stainless Steel S-shaped cam-locking lever provides desirable benefits over traditional screw knob clamps.

The TA-LBC replaces the traditional platform of the RRS Series-3 Leveling Base (TA-3-LB), or the RRS Series-2/Universal Leveling Base (TA-2U). Quick release plate not included. If mounting tripod heads to the TA-LBC see TH-DVTL-40 or TH-DVTL-55.


  • Replaces traditional platform of RRS Series-3 Leveling Base (TA-3-LB) and Series-2/Universal Leveling Base (TA-2U)
  • 12 mm Bullseye level
  • Easy Top-Loading: In one quick action, the clamp can go from closed to fully open, allowing easy top-loading of Arca-Swiss-compatible quick-release camera and lens plates. No more lost shots while fumbling to feed the plates into the end of the clamp.
  • Visual Confirmation of Lock Position: You can readily observe if the lever is locked, half-open or fully open.
  • Low Profile: The lever does not protrude above or below the top or bottom of the clamp, and, in the closed position, the lever closely hugs the contours of the clamp. This makes it less of a "weed catcher" in the field and reduces the chance of being damaged in a fall.
  • Less Abrasive, No Twisting: The smooth contours of the lever are less abrasive than standard knurled knobs, and for those with arthritic hands, the graceful lever cams open and closed with just finger force.
  • Super Tough, Reliable: The Stainless Steel lever delivers a lifetime of wear and rides on a self-lubricating, wear-resistant bronze bearing surface. Delivers 50 lbs. of holding power under full compression (the fully closed position) with our plates. This is more than sufficient for any practical photographic application.


Country of Origin: USA
  • Jaw Length: 2.4" / 60mm
  • Width: 4.3" / 108mm
  • Height: 0.75" / 19mm
  • Weight: 5.3 oz / 150g

In The Box

  • (1) TA-LBC lever release clamp
  • (4) Cap head screw, stainless steel, #6-32 x 3/8"
  • (1) 7/64" hex-key
  • (1) 5/64" hex-key
  • (1) QR-Code Reference Card for User Manual
